Nut and Thread Detection Components
Nut and Thread Detection Components
Reduce costly product rejects
- Detect missing Nuts at weld station
- Verify thread detection and quality
- Can be used as a location pin when using toughened version
- Suitable in Heavy Duty Application
- Easy to calibrate
- Cost effective
Operating on the same principle as a radial inductive proximity switch, the Syron Nut Sensors detect the presence of a welded nut and also the quality of the thread.
The all stainless steel probe resists weld spatter, and the sensing circuitry will not be damaged by the weld field environment.. This allows the sensor to be very close to the welding operation for detection of an incorrect built part in the assembly process.
The Syron Nut Sensor range covers M4, M5, M6, M8, M10 and M12 nut sizes and it is paired with a remote monitor providing a PNP or NPN output signal.
Most applications use the sensor probe Spring mount SAB30403. This mount allows the probe to retract if forced against a part with no hole and the tip can offset at up to 5 degree angle to locate misaligned holes.
